Install OpenStack on RHEL6 Using “packstack”

Install OpenStack on RHEL6 Using “packstack”

The perquisites are to have sufficient memory and to turn off selinux or set it to permissive. Changes to SELinux require a reboot. You also need sudo access, I ran packstack from my control node.

[root@ap2v ~]# cat /etc/selinux/config
# This file controls the state of SELinux on the system.
# SELINUX= can take one of these three values:
#     enforcing - SELinux security policy is enforced.
#     permissive - SELinux prints warnings instead of enforcing.
#     disabled - No SELinux policy is loaded.
# SELINUXTYPE= can take one of these two values:
#     targeted - Targeted processes are protected,
#     mls - Multi Level Security protection.

First add the RHEL6 repo – you can also install from RPM – and install packstack using yum

[root@ap2v ~]# yum install -y
[root@ap2v ~]# yum install -y openstack-packstack

Configure NTP on the nodes. This is not a must but is a good to have. Install ntp and sync up with your ntp server. I used a public ntp server in my configuration.

[root@ap2v ~]# yum install ntp
[root@ap2v ~]# chkconfig ntpd on
[root@ap2v ~]# ntpdate
[root@ap2v ~]# /etc/init.d/ntpd start

Now, since I wanted to make modifications to the default packstack install, I generated a file that contained the install configuration. This file is called “answer file” and I put my configuration preferences in it. I then told packstack to use that file to do the install. This answer file is also used if you need to make changes to the openstack cluster, for example if you wanted to add a node. You would use the same process, make changes to the answer file to reflect that a new node has been added and again run packstack and point it to modified the answer file.
I generated the answer file

[root@ap2v ~]# packstack –gen-answer-file=/root/my_answers.txt
[root@ap2v ~]# vi my_answers.txt

The answer file defaults to putting all the openstack modules in one node.

I made changes to ensure that my swift node was installed in my compute node running on a unified computing system

UCS B200 blade. I left the swift proxy node in the control node. Node is my compute node and node is my control node.

# A comma separated list of IP addresses on which to install the
# Swift Storage services, each entry should take the format
# [/dev], for example will install /dev/vdb
# on as a swift storage device(packstack does not create the
# filesystem, you must do this first), if /dev is omitted Packstack
# will create a loopback device for a test setup

#The IP address on which to install the Swift proxy service

I installed Cinder in my compute node.

# The IP address of the server on which to install Cinder

I installed nova compute in my compute node. If on a later date I wanted to add a second compute node, I would come make the changes here.

# A comma separated list of IP addresses on which to install the Nova
# Compute services

I also set public interface for Nova Network on the control node to be eth0

# Public interface on the Nova network server

And set the private interface for Nova Network dhcp on the control nodes and private interface of the Nova

# Private interface for Flat DHCP on the Nova network server

# Private interface for Flat DHCP on the Nova compute servers
# Whether to provision for demo usage and testing. Note that
# provisioning is only supported for all-in-one installations.

And set the Password of admin user

# The password to use for the Keystone admin user

At this point I was done and was ready to start the install. During the install, you will be prompted for the compute nodes root password.

[root@ap2v ~]# packstack –answer-file=/root/my_answers.txt
Welcome to Installer setup utility
Packstack changed given value  to required value /root/.ssh/
Clean Up...                                              [ DONE ]
Adding pre install manifest entries...                   [ DONE ]
Setting up ssh keys...root@'s password:
.. :                                             [ DONE ] :                                            [ DONE ] :                                       [ DONE ]
Applying            [ DONE ] :

A few 5-15 minutes later the install will complete.

[root@ap2v ~]# nova-manage service list
Binary           Host                                 Zone             Status     State Updated_At
nova-consoleauth                 internal         enabled    :-)   2015-02-04 08:30:49
nova-cert                 internal         enabled    :-)   2015-02-04 08:30:49
nova-conductor                 internal         enabled    :-)   2015-02-04 08:30:49
nova-scheduler                 internal         enabled    :-)   2015-02-04 08:30:49
nova-network     localhost 	                      internal         enabled    :-)   2015-02-04 08:30:50
nova-compute     localhost				   nova            enabled    :-)   2015-02-04 08:30:53

To log in, you naviage to glance on your browser from Username is admin. Password would have been auto generated for you when you created the answer file.

You can also grep the keystonerc_admin file generated in the install directory

[root@ap2v ~(keystone_admin)]# cat keystonerc_admin
export OS_USERNAME=admin
export OS_TENANT_NAME=admin
export OS_PASSWORD=mypassword
export OS_AUTH_URL=
